TUBE
O.D.
D

NPT MALE
PIPE SIZE
SIZE G

WINSEAL NUMBER

L

L1

I

F

H

d

3

1/8

-3MBT-2TG

23.8

11.9

9.7

12.0

11.0

2.4

3

1/4

-3MBT-4TG

24.6

14.3

14.2

14.0

11.0

2.4

6

1/8

-6MBT-2TG

26.2

13.5

9.7

12.7

14.0

4.8

6

1/4

-6MBT-4TG

27.8

14.3

14.2

14.0

14.0

4.8

8

1/4

-8MBT-4TG

28.6

15.9

14.2

15.0

16.0

6.4

10

1/4

-10MBT-4TG

29.4

15.9

14.2

18.0

19.0

7.1

12

3/8

-12MBT-6TG

34.9

19.1

14.2

21.0

22.0

10.3

12

1/2

-12MBT-8TG

36.5

20.6

19.0

22.0

22.0

10.3

TUBE
O.D.D

NPT MALE
PIPE SIZE
G

WINSEAL NUMBER

L

L1

I

F

H

d

1/8

1/8

-2IMB-3-2TG

1.86

.70

.38

7/16

7/16

.09

1/8

1/4

-2IMB-3-4TG

1.94

.92

.56

9/16

7/16

.09

3/16

1/8

-3IMB-3-2TG

1.92

.70

.38

7/16

1/2

.12

1/4

1/8

-4IMBT-3-2TG

2.12

.74

.38

1/2

9/16

.19

1/4

1/4

-4IMBT-3-4TG

2.12

.92

.56

9/16

9/16

.19

5/16

1/8

-5IMBT-3-2TG

2.34

.82

.38

5/8

5/8

.19

3/8

1/4

-6IMBT-3-4TG

2.40

1.00

.56

5/8

11/16

.28

3/8

3/8

-6IMBT-3-6TG

2.62

1.11

.36

11/16

11/16

.28

1/2

3/8

-8IMBT-3-6TG

2.84

1.11

.56

13/16

7/8

.38

1/2

1/2

-8IMBT-3-8TG

2.84

1.30

.75

7/8

7/8

.41

5/8

1/2

-10IMBT-3-8TG

3.06

1.41

.75

1

1

.47

3/4

3/4

-12IMBT-3-12TG

1   3.14

1.45

.75

1-1/16

1-1/8

.62
