TUBE
O.D.
D

WINSEAL NUMBER

L

H

HI

d

6

-6MU - 6

41.1

14

14

4.8

8

-8MU - 6

43.3

15

16

6.4

10

-10MU - 6

46.3

18

19

7.9

12

-12MU - 6

51.3

22

22

9.5

14

-14MU - 6

52.1

24

25

11.1

15

-15MU - 6

52.1

24

25

11.9

16

-16MU - 6

52.0

24

25

12.7

18

-18MU - 6

53.5

27

30

15.1

20

-20MU - 6

55.0

30

32

15.9

22

-22MU - 6

55.0

30

32

18.3

25

-25MU - 6

65.0

35

40

21.8

TUBE
O.D.
D

WINSEAL NUMBER

L

H

HI

d

1/16

-1IMU - 6

.99

5/16

5/16

.05

1/8

-2IMU - 6

1.40

7/16

7/16

.09

3/16

-3IMU - 6

1.47

7/16

1/2

.12

1/4

-4IMU - 6

1.61

1/2

9/16

.19

5/16

-5IMU - 6

1.69

9/16

5/8

.25

3/8

-6IMU - 6

1.77

5/8

11/16

.28

1/2

-8IMU - 6

2.02

13/16

7/8

.41

5/8

-10IMU - 6

2.05

15/16

1

.50

3/4

-12IMU - 6

2.11

1-1/16

1-1/8

.62

7/8

-14IMU - 6

2.17

1-3/16

1-1/4

.72

1

-16IMU - 6

2.55

1-3/8

1      1-1/2

.88
